Forms: Single/Double
Product Origin: China
Color: Black / White / Brown
HS Code: 591190
✅ Temperature Range: -196℃ to +260℃ continuous (300℃ peak)
✅ Dielectric Strength: 100kV/mm min (ASTM D149)
✅ Chemical Resistance: HF/Aqua regia proof
✅ Adhesion: 1.5N/cm² initial tack (FINAT), 24h@100℃ holding power
✅ Certifications: UL 510 flame rated, RoHS 2.0 compliant
✅ Electronics: SMT reflow masking, high-frequency transformer insulation
✅ Chemical Processing: Reactor flange sealing, corrosive pipe joint protection
✅ Food Equipment: Heat sealer roller wrapping, non-stick baking mold lining
✅ Aerospace: Engine wiring harness bundling, high-temperature sensor shielding
Parameter |
Typical Value |
Test Method |
Thickness |
0.08mm-0.25mm |
ISO 4593 |
Tensile Strength |
≥50N/10mm |
ASTM D882 |
Peel Adhesion |
3-8N/cm |
PSTC-101 |
Voltage Rating |
AC 5kV withstand |
IEC 60243 |
Performance Advantages:
Non-carbonizing Cold-flow resistant Non-contaminating Precision die-cuttable
